Aoki Model SBIII-500N-60 PET Injection Stretch Blow Molding Machine

Aoki Model SBIII-500N-60 PET Injection Stretch Blow Molding Machine

– (2) available

– Year of manufacture- 2003

– Offer can include a series of injection (preform) molds and several blow molds at an attractive additional price

– Condition- Very good- taken out of production in approximately October 2020

Description

Aoki Model SBIII-500N-60 PET Injection Stretch Blow Molding Machine


– (2) available
– PET One-Step
– Year of manufacture- 2003
– Injection capacity- 526 cubic centimeters per shot
– Pump motor size- 55 kW
– Heater capacity- 18.69 kW
– Product size capabilities:

Number of Products: 12 14 16 18 20
Mouth Diameter (mm): 40 35 35 30 24
Body Diameter (mm): 70 64 55 46 40
Height (mm): 150 150 150 150 150
Approx Capacity (ml): 500 400 300 200 150

– Machine dimensions (meters)- 5.38 length x 2.64 width x 3.39 height
– Machine weight (kilograms)- 14,000
– Electrical specifications- 460 volts/3 phase/60 Hz
– Offer can include a series of injection (preform) molds and several blow molds at an attractive additional price
– Condition- Very good- taken out of production in approximately October 2020
