Description
Aoki Model SBIII-500N-60 PET Injection Stretch Blow Molding Machine
– (2) available
– PET One-Step
– Year of manufacture- 2003
– Injection capacity- 526 cubic centimeters per shot
– Pump motor size- 55 kW
– Heater capacity- 18.69 kW
– Product size capabilities:
| Number of Products: | 12 | 14 | 16 | 18 | 20 |
| Mouth Diameter (mm): | 40 | 35 | 35 | 30 | 24 |
| Body Diameter (mm): | 70 | 64 | 55 | 46 | 40 |
| Height (mm): | 150 | 150 | 150 | 150 | 150 |
| Approx Capacity (ml): | 500 | 400 | 300 | 200 | 150 |
– Machine dimensions (meters)- 5.38 length x 2.64 width x 3.39 height
– Machine weight (kilograms)- 14,000
– Electrical specifications- 460 volts/3 phase/60 Hz
– Offer can include a series of injection (preform) molds and several blow molds at an attractive additional price
– Condition- Used- taken out of production in approximately October 2020
